J305HG-AC 6V Flooded Lead Acid Battery

The J305HG-AC 6V Flooded Lead Acid battery provides high-power output to supply enough energy for applications including Marine, Solar, and Floor Cleaning Machines. This AC battery offers high- to low-capacity points to improve performance and meet economic needs.

BAttery Quick Facts
Capacity Minutes

@25 Amps / 781 @75 Amps / 215

Capacity Amp-Hours

5-Hr Rate / 295 Ah 10-Hr Rate / 331 Ah 20-Hr Rate / 360 Ah 100-Hr Rate / 400 Ah

Energy (kWh)

2.40

Dimensions inches (mm)

Length / 12.17 (309) Width / 6.85 (174) Height / 14.41 (366)

Weight lbs. (kg)

98 (45)

Operating Temperature

-4°F to 113°F (-20°C to +45°C)

Features & Benefits

  • AC Series™ offers high- to low-capacity points
  • Maxguard® Advanced Design Separator and Alpha Plus® paste formulation for long life, industry-leading performance and lower overall maintenance costs.
  • Two battery case options:
  • Polyon™ case for exceptional durability in heavy service applications
  • Generic case design for standard applications
  • Heat and corrosion resistant
  • With braided rope handles for easy carrying
  • HydroLink™ single-point watering system available
  • Only 5-15% self-discharge per month
  • 99% recyclable

TERMINAL TYPES

0

Universal Terminal UT
